Three ways to smuggle SQLite into Nix
The core of nixpkgs-multiverse, when you strip away the Nix API and the CLI, is an index. It is a map from (attribute, version) to the revision that shipped it as a JSON file.1
$ ls -lh index/
-rw-r--r--. 1 fmzakari fmzakari 7.5M Aug 19 13:57 history.json
-rw-r--r--. 1 fmzakari fmzakari 5.3M Aug 19 13:57 versions.json
As of 9cc0209, versions.json is 5.3 MiB and history.json is 7.5MiB covering 305,492 package versions across 31,904 packages and 1,534 revisions.
The Nix API loads the JSON files lazily and are all read via builtins.fromJSON:
index = builtins.fromJSON (builtins.readFile ./index/versions.json);
I would like to enrich the data with even more information however it comes at a cost: mo’data, mo’problems.
The goal of the project is to minimize the number of Nixpkgs that are downloaded. If we merely swap fetching huge Nixpkgs for huge JSON, it’s not a clear win.
For now we have to be judicious about what we store in the JSON files and think of clever encoding schemes to make the data small and compact.
If we were not constrained to the Nix builtins, we would leverage established technologies to efficiently encode our dataset that allow multiple query access patterns: databases!
Let’s say we were not restricted to JSON, do we have any other options?
One lookup costs the whole file
Why are large JSON files so problematic? builtins.fromJSON is eager. There is no lazy JSON in Nix, no streaming parse (i.e. “just give me this one key”). The moment you touch the result you have parsed all 5.3 MB and materialised all 305,492 values on the Nix heap.
In the case of the multiverse, asking for one package costs the same as what asking for all of them.
Note The lookup itself is not the problem. Nix attribute sets are a sorted array, so access is a binary search, not a scan. The cost is entirely in the JSON parse and in allocating the values and downloading a large file.
If we want to do alternate questions over the index, we have to make sure we keep the answers efficiently stored to better match the access pattern.
What we want is obvious. We want a way to efficiently encode the data and a declarative way to define queries: we want SQLite!2
$ sqlite3 index.db "SELECT version, rev FROM versions WHERE attr='hello'"
2.10|728
...
0.01s, 4 MB
Nix by default cannot do this. Unfortunately there is no builtins.sqlite, although I think there should be…
Turns out though there are knobs we can touch or sources we can patch to get what we want anyways, albeit each one has a caveat. 😈
One: builtins.exec
I was surprised I did not know about this builtin, and it has been around since release 1.11.9 in April 2017. It is the ultimate escape hatch for a variety of use-cases when you simply can’t get them done with what’s available.
builtins.exec takes a list of strings, runs the program, and parses its stdout as a Nix expression.
It is gated behind a setting that makes it clear it’s unsafe.
$ nix eval --option allow-unsafe-native-code-during-evaluation true \
--expr 'builtins.exec [ "/bin/sh" "-c" "echo 42" ]'
42
For integration, SQLite is perfectly capable of printing the Nix syntax. We never need a serialisation format in between as we make SQLite emit the attrset directly:
let
versionsOf = attr: builtins.exec [
"${sqlite}/bin/sqlite3" "-noheader" "-separator" "" "./index.db"
''
SELECT '{' || group_concat(
'"' || version || '" = ' ||
COALESCE(CAST(rev AS TEXT), 'null') || ';', ' ')
|| '}'
FROM versions WHERE attr = '${attr}';
''
];
in
versionsOf "hello"
$ nix eval --impure -f query.nix \
--option allow-unsafe-native-code-during-evaluation true
{
"2.10" = 728; "2.12" = 822; "2.12.1" = 1369;
"2.12.2" = 1486; "2.12.3" = null; "2.7" = 0; "2.8" = 13;
}
The caveat is that every query is now a fork, an exec, a process image of SQLite, and a re-parse of the output through the Nix parser. If you do not plan to execute many queries that overhead is likely acceptable given the simplicity of the integration.
Two: builtins.importNative
From researching builtins.exec, I stumbled upon builtins.importNative. It takes a path to a shared object and a symbol name, dlopens it, and calls that symbol. It landed in 1.8, December 2014.3
The shared object must implement the following signature:
extern "C" typedef void (*ValueInitializer)(EvalState & state, Value & v);
We can define a new native function that returns the versions for our input:
extern "C" void nix_sqlite_versions(EvalState & state, Value & v)
{
v.mkPrimOp(new PrimOp{
.name = "nix_sqlite_versions",
.args = {"dbPath", "attr"},
.arity = 2,
.impl = versions,
});
}
The implementation is ordinary C++ using the Nix API. Below is a snippet of the implementation, making sure to cache our sqlite3 handles to avoid the same startup penalty as builtins.exec:
/* The whole point: the database handle outlives a single query, so the
b-tree pages we touch stay warm for the rest of the evaluation. */
std::map handles;
void versions(EvalState & state, const PosIdx pos,
Value ** args, Value & v)
{
std::string path(state.forceStringNoCtx(*args[0], pos, "..."));
std::string attr(state.forceStringNoCtx(*args[1], pos, "..."));
// cached across calls
auto * db = openOnce(state, pos, path);
sqlite3_stmt * stmt = nullptr;
sqlite3_prepare_v2(db,
"SELECT version, rev "
"FROM versions "
"WHERE attr = ?1",
-1, &stmt, nullptr);
sqlite3_bind_text(stmt, 1, attr.data(),
attr.size(), SQLITE_TRANSIENT);
/* ... collect rows ... */
/* Build the attrset directly. No text ever exists. */
auto bindings = state.buildBindings(rows.size());
for (auto & [version, rev] : rows) {
auto & slot = bindings.alloc(state.symbols.create(version));
if (rev) slot.mkInt(*rev); else slot.mkNull();
}
v.mkAttrs(bindings);
}
Using it looks like this:
$ nix eval --impure \
--option allow-unsafe-native-code-during-evaluation true \
--expr '(builtins.importNative
./libnixsqlite.so "nix_sqlite_versions"
) "./index.db" "hello"'
{
"2.10" = 728; "2.12" = 822; "2.12.1" = 1369;
"2.12.2" = 1486; "2.12.3" = null; "2.7" = 0; "2.8" = 13;
}
Three: builtins.wasm
Determinate Systems shipped a third option in March of 2026: builtins.wasm, which calls a function inside a WebAssembly module.4 The motivation was similar to wanting to extend Nix surface area but avoid expanding builtins. Wasm is sandboxed and deterministic, so unlike the two builtins above, the goal is to provide a safe escape-hatch.
WebAssembly is a binary instruction format for a stack-based virtual machine. The claim is that it is well suited for Nix because it has deterministic execution, which is a lot more restrained than a backdoor builtins.exec.
Writing a module
A module needs to export memory, an initialiser called nix_wasm_init_v1, and the entry point.
#![no_std]
#![no_main]
type ValueId = u32;
#[panic_handler]
fn panic(_: &core::panic::PanicInfo) -> ! {
core::arch::wasm32::unreachable()
}
// Host functions supplied by the Nix evaluator.
#[link(wasm_import_module = "env")]
unsafe extern "C" {
fn get_int(v: ValueId) -> i64;
fn make_int(n: i64) -> ValueId;
}
#[unsafe(no_mangle)]
pub extern "C" fn nix_wasm_init_v1() {}
fn fib(n: i64) -> i64 {
if n <= 1 { 1 } else { fib(n - 1) + fib(n - 2) }
}
#[unsafe(no_mangle)]
pub extern "C" fn fib_entry(arg: ValueId) -> ValueId {
unsafe { make_int(fib(get_int(arg))) }
}
Nixpkgs already includes the target for cross-compilation, so making one is pretty straightforward:
pkgs.runCommand "nix-wasm-rust-fib"
{
nativeBuildInputs = [ pkgs.rustc pkgs.lld ];
src = ./modules.rs;
} ''
mkdir -p $out
rustc --target wasm32-unknown-unknown --crate-type cdylib -O \
-o $out/modules.wasm $src
''
$ nix eval --extra-experimental-features wasm-builtin \
--expr 'builtins.wasm { path = ./modules.wasm;
function = "fib_entry"; } 30'
1346269
You call back into the evaluator through the Nix API functions, so a wasm module builds real Nix values, similar to builtins.importNative minus the footgun.
Can I haz SQLite?
SQLite ships an official wasm build, so the pieces seem to be sitting right there and the gears in my mind began to turn.
Initial attempts to try and load a SQLite database with the traditional Nix builtins were a bit of a failure as Nix strings cannot contain NULL bytes.
$ nix eval --impure --expr 'builtins.stringLength (builtins.readFile ./index.db)'
error: the contents of the file '/tmp/mvsql/index.db' cannot be represented as a Nix string
Thankfully, with the help of some additional due-diligence by LLMs, we discovered that one of the Nix API functions is not in the blog post:
/**
* Read the contents of a file into Wasm memory. This is like calling
* `builtins.readFile`, except that it can handle binary files that
* cannot be represented as Nix strings.
*/
uint32_t read_file(ValueId pathId, uint32_t ptr, uint32_t len)
read_file is specifically designed for this problem. This function allows a WASM module to pull arbitrary raw-bytes off disk into its memory.
Unfortunately, it’s a little too broad in that it reads the complete file which is kind of overkill and what we are trying to avoid from our initial JSON solution.
In the pursuit of exploration, let’s patch the implementation and augment the API to allow random access and partial read of a file. Turns out the patch to add is relatively small and straightforward.
/**
* Read a range of a file into Wasm memory, starting at `offset`
* and copying at most `len` bytes.
* Returns the number of bytes actually copied.
*/
uint32_t read_file_range(ValueId pathId, uint64_t offset,
uint32_t ptr, uint32_t len)
{
auto & pathValue = getValue(pathId);
auto path = state.realisePath(noPos, pathValue);
auto buf = memory().subspan(ptr, len);
/* If this is a real file on disk, do a positional read*/
if (auto physical = path.getPhysicalPath()) {
AutoCloseFD fd{open(physical->string().c_str(),
O_RDONLY | O_CLOEXEC)};
if (!fd)
throw SysError("opening file '%s'", physical->string());
auto n = pread(fd.get(), buf.data(), len, offset);
if (n < 0)
throw SysError("reading file '%s'", physical->string());
return n;
}
/* Otherwise fall back to materialising the whole file. */
auto contents = path.readFile();
if (offset >= contents.size())
return 0;
auto n = std::min(len, contents.size() - offset);
memcpy(buf.data(), contents.data() + offset, n);
return n;
}
Now we have everything we need to hook up SQLite and a custom virtual filesystem (VFS) layer to read from the provided /nix/store path entry.
We build a WASM target of SQLite and we set SQLITE_OS_OTHER=1. That flag removes SQLite’s entire VFS layer and requires us to supply one.
pkgs.pkgsCross.wasi32.stdenv.mkDerivation {
pname = "sqlite-nix-wasm";
buildPhase = ''
$CC -O2 -o sqlite_nix.wasm \
-I${amalgamation} ${amalgamation}/sqlite3.c sqlite_nix.c \
-DSQLITE_OS_OTHER=1 \
-DSQLITE_THREADSAFE=0 \
-DSQLITE_OMIT_LOAD_EXTENSION \
-DSQLITE_OMIT_WAL \
-Wl,--export-memory
'';
}
We provide the build a simple implementation of the xRead API which is a call-back into the Nix evaluator via that newly exposed nix_read_file_range function. Everything else is stubs.
static const sqlite3_io_methods nixIoMethods = {
.iVersion = 1,
.xClose = nixClose,
.xRead = nixRead,
.xFileSize = nixFileSize,
.xDeviceCharacteristics = nixDeviceCharacteristics,
/* ... the rest are stubs ... */
};
static int nixRead(sqlite3_file *f, void *buf,
int amt, sqlite3_int64 off)
{
NixFile *p = (NixFile *) f;
/* The one line that matters: SQLite's pager asks
for a page, and we ask the Nix evaluator for
exactly those bytes. */
unsigned got = nix_read_file_range(p->pathId, (unsigned long long) off,
buf, (unsigned) amt);
if (got < (unsigned) amt) {
memset((char *) buf + got, 0, (unsigned) amt - got);
return SQLITE_IOERR_SHORT_READ;
}
return SQLITE_OK;
}
Note Unfortunatelybuiltins.wasmgives every call a fresh instance. This is deliberate from the implementation, meaning we pay some startup code each time although not quite as drastic as afork&exec
Using it looks like this:5
$ nix eval --extra-experimental-features wasm-builtin \
--expr 'builtins.wasm { path = ./sqlite_nix.wasm; }
{ db = ./index.db; attr = "hello"; }'
{
"2.10" = 728; "2.12" = 822; "2.12.1" = 1369;
"2.12.2" = 1486; "2.12.3" = null; "2.7" = 0; "2.8" = 13;
}
That is a real full SQLite with all the bells and whistles: prepared statement, bound parameter, b-tree descent through an index, executing inside the Nix evaluator. All through WebAssembly. 🤯
Benchmark
How do these four approaches compare? Here are all four approaches answering the same question: “which revisions shipped this package?” against the same 22 MB SQLite build of the index.
import pandas as pd
from plotnine import *
# Best of five runs each. Random attributes drawn from the real index.
# `nix eval --expr '1+1'` costs 0.03s, the floor every line sits on.
# The first three run on stock Nix 2.34.7; the wasm line needs the patched
# Determinate Nix, whose baseline is the same 0.03s.
rows = [
("builtins.fromJSON", [0.29, 0.30, 0.27, 0.29]),
("builtins.exec", [0.05, 0.08, 0.22, 0.74]),
("builtins.importNative", [0.05, 0.04, 0.05, 0.05]),
("SQLite in wasm", [2.79, 2.46, 3.10, 4.37]),
]
queries = [1, 10, 50, 200]
df = pd.DataFrame({
"queries": queries * len(rows),
"seconds": [v for _, vs in rows for v in vs],
"how": [k for k, vs in rows for _ in vs],
})
plot = (
ggplot(df, aes("queries", "seconds", color="how"))
+ geom_line(size=1.0)
+ geom_point(size=1.8)
+ scale_x_log10(breaks=queries, labels=[str(q) for q in queries])
+ scale_y_log10()
+ scale_color_manual(values={"builtins.fromJSON": "#8a8580",
"builtins.exec": "#4c72b0",
"builtins.importNative": "#b1201d",
"SQLite in wasm": "#d1892f"},
name="")
+ labs(x="point queries in one evaluation", y="seconds (log scale)")
+ theme(legend_position="top", legend_title=element_blank())
)
plot.width, plot.height = 7.0, 3.8
As we initially complained, fromJSON is a flat line in the wrong place. It is 0.29s whether you ask one question or two hundred, because the 5.3 MB parse happens once and dominates everything after it.
builtins.exec starts the cheapest and climbs, roughly 3.8 ms per query of fork + exec + Nix-parsing the output. It crosses fromJSON somewhere around eighty queries.
builtins.importNative is flat and nearly free, 0.05s across the whole range since we reuse SQLite instantiations across multiple invocations. The database is opened once for the entire evaluation and the pages stay warm.
Unfortunately, SQLite in wasm is dominated by a fixed cost, roughly 2.5 s before the first query, then about 7 ms each query thereafter. That 2.5 s is Cranelift compiling 1.1 MB of SQLite. Right now that is a limitation of the WASM implementation however Eelco has mentioned that the generated code could be cached on disk in the future across invocations.
For a lock file pinning thirty packages, fromJSON still wins outright at the current index size.
What I actually want
None of these three is right for shipping the multiverse index, and I am not going to make nixpkgs-multiverse depend on allow-unsafe-native-code-during-evaluation. Asking people to run their evaluator with native code loading enabled so my flake can be faster is not a worthwhile request at the moment.
For now, the index stays JSON and I’m holding back on some of the more loftier ideas I have that require a lot more data.
Although philosophically I only use CppNix, I was a little intrigued and impressed with what the ecosystem could unlock with WASM. There are definitely some warts however such as waiting for it to JIT and the developer-experience of maybe having checked-in compiled blobs but there is definitely potential to unlock a variety of problems.
- There are actually a few other files that drive other features such as the statistics or “fast mode”, but they are all JSON as well. ↩
- nixpkgs-multiverse already exports a SQLite database as a package to help others explore this data. ↩
- The C++ field was originally called
enableImportNativeand was renamed toenableNativeCodeforexec. ↩ - Eelco gave a talk about this at SCALE 23x. ↩
- Don’t forget that this is needs our patched version of Determiante System’s Nix. ↩
